350-700kW Containerized Germany-MAN-Gas-Engine Generator/CHP Set

Name: 350-700kW Containerized Germany-MAN-Gas-Engine Generator/CHP Set
SKU: 0

the sole authorized integrator of Germany-MAN, offer high-end power solutions that combine world-class engineering with ultimate reliability. Our generation and Combined Heat and Power (CHP) systems perfectly pair genuine Germany-MAN gas engines with top-tier imported alternators like Stamford to deliver unmatched efficiency and performance

Telephone.0086 13668267277（Domestic）

Telephone.0086 13980857986（International）

Mailbox:info@cnamico.com

Message

More Information

Technical Parameters

Parameter Table
Serial number	Parameter name	Specification
1	unit	500kW containerized MAN-gas-engine generator set
1.1	Unit Model	AMC500NS
1.2	Rated Power	500kW
1.4	Rated current	902A
1.5	Rated voltage	230/400V
1.6	Rated frequency	50Hz
1.7	Power Factor	0.8 (lagging)
1.8	Startup method	DC24V electric start
1.9	Speed regulation mode	Electronic speed control
1.10	Fuel control method	Lean burn, closed loop control
1.11	Ignition method	Electronically controlled single cylinder independent high energy ignition
1.12	Unit operation type	One-key automatic start, one-key paralleling, one-key delivery; one-key shutdown, etc.
1.13	Unit dimensions	20'GP container
1.14	Unit weight	9200kg

Note: Products with other voltage levels and frequencies can be provided. If you have any questions, please feel free to consult.

Technical characteristics

1. Economy

Improve air-fuel ratio, reduce emissions, extend engine lifespan, and lower maintenance costs
Precise control of fuel combustion, improving fuel economy by 5-10%
Control system certified by CCS, reliable quality, stable operation, and low post-operation maintenance costs

2. Responsiveness

Ultra-fast fuel injection valve controls fuel supply, enabling instant engine response to meet surge load demands. Proven in large oil fields (drilling, hydraulic fracking) and factory fluctuating conditions.

3. Emissions

Complies with China National V emission standards or non-road T3+ standards
NOx below 200ppm

4. Others

Delivery 5 months after advanced payment.
"Plug-and-play" integrated design, fastest 1-day electrification; facilitates project relocation
Comprehensive protection, 20 years of project experience,0 accidents
Full lifecycle software upgrading services, enabling real-time site visibility.

Message acquisition plan

Pre-sales service

Our professional engineers participate in the whole process, they provide service based on the project information by our customer (such as gas source, operating conditions, environment, etc.)
